Full HD, Wide View Angle, Multiple Zoom Lens, Multiple Video Interfaces and Multiple protocols. This camera offers perfect functions, superior performance and rich interfaces. The features include advanced ISP processing algorithms to provide vivid images with a strong sense of depth, high resolution and fantastic color rendition.
A high-definition video conference camera with advanced features and superior performance for conference rooms and classrooms.
1/2.9 inch high quality CMOS sensor with 1920×1080 resolution at 30fps
Powerful zoom with 8.8° to 70° view angle for SMART board coverage
Intelligent image processing with AWB, AE and AF functions
High SNR with 2D/3D noise reduction technology
RS232, RS485 support with daisy chain capability
Low-power sleep and wake up function
255 preset positions with 10 preset by remote control
USB connection with no driver installation required
| Model Number | 10x Zoom |
| Image Sensor | 1/2.9 Inch High Quality CMOS Sensor |
| Effective Pixels | 2.07MP, 16:9 |
| Video Format | 1920×1080P@30 fps/25fps; 1280×720P@30fps/25fps; 1024×576P@30fps/25fps; 960×540P@30fps/25fps; 800×448P@30fps/25fps; 640×360P@30fps/25fps; 320×176P@30fps/25fps |
| Optical Lens | f＝4.34mm～41.66mm |
| View Angle | 8.8°～ 70° |
| Iris | F1.85 – F2.43 |
| Optical Zoom | 10x |
| Digital Zoom | 10X |
| Low Illumination | 0.5Lux(F1.8, AGC ON) |
| DNR | 2D﹠3D DNR |
| White Balance | Auto / Manual/ One Push//3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K |
| Focus | Auto / Manual/ One Push/ |
| Exposure | Auto / Manual |
| BLC | On/Off |
| WDR | OFF/ Dynamic Level Adjustment |
| Video Adjustment | Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve |
| SNR | >50dB |
| Video Output | USB2.0 (Type A) |
| Control Port | RS232(Circuit), RS485 |
| Control Protocol | VISCA/Pelco-D/Pelco-P |
| Power Supply | HEC3800 Outlet (DC12V) |
| Support OS | Windows 7, Windows8, Windows10, Mac, Linux |
| Video Compression | H.265, H.264, MJPG |
| Communication Protocol | UVC |
| Pan / Tilt Rotation | -170°~+170°, -30°~+30° |
| Pan / Tilt Control Speed | 0.~60°/Sec, 0.~30°/Sec |
| Preset Speed | Pan:60°/Sec, Tilt: 30°/Sec |
| Preset Numbers | 255 Points Preset (10 points By Remote Controller) |
| Working Voltage | 12V |
| Working Current | 0.25A(max) |
| Power Consumption | 2.5W(max) |
| Storage Temperature | -10℃~+60℃, 20%~95% |
| Working Temperature | -10℃~+50℃, 20%~80% |
| Dimension | 156.8mm×112.6mm×139.5mm |
| Weight | About 1kg |
| Usage | Indoor Only |
| Package Contents | Power supply, Remote Controller, Manual, Warranty Card, USB2.0 Cable |
| Optional Accessories | Mount (Extra Cost) |
