The Rocware RC841U 4K UHD Video PTZ Camera features Sony's 1/2.5 inch CMOS sensor delivering stunning 4K quality at 30 fps. With an 80.8° horizontal angle and 12X lossless optical zoom, it provides exceptional coverage for conference rooms.
Advanced AI humanoid tracking and auto-framing capabilities ensure perfect focus on individual or all team members, while the silent mechanical PTZ system offers smooth, quiet operation with ±170° horizontal and -30°~+90° vertical rotation.
* Price excludes taxes, shipping, installation, setup, service fees, and additional charges. Contact sales for a customized quote.
A high-definition video conference camera specially designed for large and medium-sized conference scenarios, featuring advanced AI capabilities and superior image quality.
8 million pixel SONY CMOS sensor delivering 3840x2160 resolution
80.8° wide-angle lens with 16x digital zoom capability
Automatic participant recognition and framing
Smooth, quiet operation with wide rotation range
Over 55dB ratio with advanced noise reduction
HDMI, USB3.0, and network interface support
Perfect for 60-100㎡ conference rooms
>30000 hours mean time between failures
| Signal | HDMI: 4KP30fps, 4KP25, 1080P30, 1080P25 |
| USB | USB 3.0, TypeC* 1 |
| HD Output | HDMI 1.4b *1 |
| Network Interface | RJ45：10M/100M *1 |
| Audio Interface | Line In, 3.5mm *1 |
| Communication Interface | RS232 In: *1 |
| Power Connector | DC 12V / PoE(802.3af) |
| Video Encoding Standards | H.264/MJPEG |
| Video Stream | The first stream, the second stream |
| First Stream Resolution | 3840x2160, 1920x1080, 1280x720, 1024x576, 960x540, 640x480, 640x360 |
| Second Stream Resolution | 1920x1080, 1280x720, 1024x576, 720x576, 720x480, 720x408, 640x360, 480x270, 320x240, 320x180 |
| Video Bit Rate | 32Kbps ~ 102400Kbps |
| Bit Rate Control | Variable bit rate, fixed bit rate |
| Frame Rate | 50Hz: 1fps ~ 25fps, 60Hz: 1fps ~ 30fps |
| Audio Compression Standards | AAC |
| Audio Bit Rate | 96Kbps, 128Kbps, 256Kbps |
| Support Agreement | TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, multicast |
| OS Support | Windows 7, Windows 8, Windows 10, Mac OS X, Linux, Android |
| Color Space/Compression | YUY2/ MJPEG/ H.264 |
| Video Format | YUY2 (iso model): Max: 1080P@30fps MJPEG: Max: 2160P@30fps H.264 AVC: Max: 2160P@30fps H.264 SVC: Max: 2160P@30fps |
| USB Audio | Support |
| USB Video Communication | UVC 1.1~1.5 |
| UVC PTZ Control | Support |
| Sensor | 1/2.5", CMOS, effective pixels: 8.51 million |
| Scanning Method | Line by line |
| Lens | 12x, f = 3.47mm ~41.65mm, F 1.84 ~ F 3.72 |
| Digital Zoom | 16x |
| Minimum Illumination | 0.5Lux @ (F1.8, AGC ON) |
| Shutter | 1/30s ~ 1/10000s |
| White Balance | Automatic, indoor, outdoor, one-touch, manual, specify the color temperature |
| Backlight Compensation | Support |
| Digital Noise Reduction | 2D & 3D digital noise reduction |
| Signal-to-Noise Ratio | ≥55dB |
| Horizontal Field of View | 80.8° ~ 7.5° |
| Vertical Field of View | 49.9° ~ 4.3° |
| Pan Range | ±170° |
| Tilt Range | -30° ~ +90° |
| Pan Speed Range | 2.7° ~ 35.7°/s |
| Tilt Speed Range | 2.7° ~ 31.5°/s |
| Flip Horizontally, Vertically | Support |
| Image Freezes | Support |
| Number of Preset | 255 |
| Preset Accuracy | 0.1° |
| Input Voltage | DC 12V / PoE(802.3af) |
| Input Current | 12V 1A |
| Operating Temperature | -10°C ~ 40°C |
| Storage Temperature | -40°C ~ 60°C |
| Power Consumption | 12W |
| Mean Time Between Failures | >30000 hours |
| Size | 142mm x 152mm x 176mm |
| Net Weight | 1.5Kg |
