ViewBoard IFP8650-5F

ViewBoard® 86" 4K Interactive Display
Ultra Fine Touch Technology offering up to 40-point touch for a pen-on-paper writing experience
myViewBoard Whiteboard software with engaging classroom tools
Screen share via USB-C or wirelessly via myViewBoard Display and ViewBoard Cast with Airplay and Chromecast
Intuitive remote device control and multimedia broadcast with myViewBoard Manager
Android 13 OS powered by an octa-core CPU for optimized efficiency and security

* Price excludes taxes, shipping, installation, setup, service fees, and additional charges. Contact sales for a customized quote.

Product Features

Designed with modern educators in mind, the ViewBoard® 50-5F Series offers an intuitive and interactive interface for a multi-user writing experience. With a single-cable USB-C for instant, worry-free connectivity, teachers can seamlessly plug-in and control their devices while continuing the lesson. Both students and educators enjoy smooth writing with Ultra Fine Touch Technology offering 40-point touch, and the dual-pen that comes in a range of colors and sizes. Rest assured you and your students' eyes are cared for and protected as the ViewBoard® 50-5F Series comes with Flicker-Free technology and an integrated TÜV certified blue light filter for all brightness levels. Fully integrated with the myViewBoard suite, the ViewBoard® 50-5F Series brings together hardware and software for a complete classroom solution. Compatible with a full line of accessories, the ViewBoard® 50-5F Series enables you to effectively teach with a variety of engaging tools.

Google Certified EDLA

Access to Google Play Store and Workspace suite with Android™ 14 launcher.

Android OS

Runs on the latest Android operating system for smooth performance

Processor

High-performance octa-core processor for fast operation

RAM

8GB DDR4 RAM for smooth multitasking

Storage

128GB storage for apps and content

4K Display

Ultra HD 3840x2160 resolution for stunning visuals

Touch Point

40-point multi-touch for seamless collaboration

Smooth Writing

Ultra Fine Touch Technology, 40-point touch, and dual-pen for a natural writing experience.

Elevated Audio Quality

Built-in dual 20W speakers for profound audio depth and immersive lessons.

One Cable to Do It All

USB-C for instant multimedia playback, data transfer, and power charging.

myViewBoard Whiteboard

Tailor-made tools for effortless lesson planning and activities, online or in-classroom.

Quick Content Sharing

Simultaneously cast up to four devices with ViewBoard Cast and myViewBoard Display.

Remote Management

Efficiently update, schedule, broadcast, and manage multiple displays with myViewBoard Manager.

Performance and Safety

Android 13 OS with an octa-core CPU for powerful performance and data protection.

Easy on the Eyes

Flicker-Free technology, TÜV-certified low blue light, and anti-glare coating.

Technical Specifications

Display	Panel Size: 86" Panel Type: TFT LCD Module with DLED Backlight. IPS Display Area (mm): 1913.0(H) x 1084.0 (V) Aspect Ratio: 16:9 Resolution: UHD 3840x2160 Colors: 1.07B colors (10bit) Brightness: 500 nits Contrast Ratio: 1200:1 (typ.) 5000:1 (DCR) Response Time: 8ms Viewing Angles: H = 178, V = 178 typ. Backlight Life: 50,000 hours (Min) Surface Treatment: Hardness: 7H, Anti-glare coating Bezel: Slim Orientation: Landscape
Platform	Processor: ARM Cortex-A734 + Cortex-A534 RAM: 8GB Storage: 64GB
Touch	Type/ Tech: Ultra Fine Touch Techology (IR Recognition) Touch Resolution: 32768 ×32768 Touch Point: Windows: 40 points of touch, Android : 20 points of touch
INPUT	HDMI: 2.0 x 3 (3840x2160 @60Hz, HDCP2.2, HDMI1 with CEC/ARC) RS232: x1 OPS: x1 WiFi: x 1 module slot
OUTPUT	HDMI: x1 (4K@60Hz) Audio: x1 (Earphone out) SPDIF: x1 (optical)
LAN	RJ45: x2
USB	Type A: 2.0 x 2 3.0 x 4 Type B: x2, for touch Type C: x1 ( DP 1.2, USB2.0, PD65W, Ethernet 100M)
SPEAKERS	20W x 2 + 20W x 1 subwoofers
Top Camera Plate	Yes
Embedded OS	Android 13
Bundle Software	Basic Annotation Software: myViewBoard Pro Annotation Software: myViewBoard for Windows (Embedded in Windows Slot-in PC) Wireless Presentation: vCast/myViewBoard Display App / AirSync* *myViewBoard Display will be replaced by AirSync in Q1 2025.
Special Features	All-in-one USB port: “SmartPort™ USB” to all channels. Simple LAN sharing between IFP and slot-in device: Yes Light Sensor: Yes
Power	Voltage: 100-240VAC +/- 10% Wide Range Consumption: 175W(typ.), 0.5W (off)
ERGONOMICS	Wall Mount (VESA® ): 800 mm x 600 mm
OPERATING CONDITIONS	Temperature (º C): 0°C to 40°C Humidity: 10% ~ 90% RH non-condensing
DIMENSIONS (W x H x D)	Physical (inch / mm): 77.05 x 45.66 x 3.41 in / 1957.1 x 1159.8 x 86.5 mm Packaging (inch / mm): 83.07 x 50.51 x 8.86 in / 2110 x 1283 x 225 mm
WEIGHT	Net (lb / kg): 147.05lb/66.7kg Gross (lb / kg): 191.58lb/86.9kg
REGULATIONS	cTUVus, FCC/ICES003, Energy Star 8.0, EMC/CE, CB/LVD, GOST-R/EAC, UkrSEPRO, EPEAT, Mexico NOM , Mexico Energy, UKCA, UK-EEL, BSMI, BIS, LBL( Low Blue Light Certification), Flicker Free, Green BOM, RoHS, ErP-Eco, REACH, SCIP, WEEE, TPCH , Packing waste, CA65, PAIA
PACKAGE CONTENTS	1. Power cord 2. Remote control with AAA battery 3. Touch USB cable 4. Touch pen x 2 (VB-PEN-009) 5. Quick Start Guide + Compliance statement 6. RS232 adapter 7. Clamp x 5 8. Camera Plate 9. Screw x 8 10. HDMI cable
Compatible Slot-in PC	• VPC2-O series • VPC2-O-B series • VPC25-W33-O1-1B • VPC27-W53-O1-1B • VPC12-WPO-17 • VPC12-WPO-18
